| Content | Specifications |
| Product name | Underground platform 1 pillar – 660 liter trash can |
| Model | BN1T-660L/TNC |
| Installation hole size
(Length x Width x Depth) |
2500 x 1650 x 1840 mm (±50mm) |
| Device dimensions
– not including pillar (Length x Width x Height) |
2075 x 1250 x 1640 mm |
| Pillar | Dimensions (LxWxH): 550 x 500 x 890 mm
Material: stainless steel Features: lid closes automatically and seals when trash is thrown away |
| 660 liter trash can – HDPE | Dimensions (LxWxH): 1260 x 770 x 1200 mm |
| Hydraulic cylinder | Two hydraulic cylinders Ø40, stroke 1300mm |
| System balance | Rack and pinion balancing system |
| Power supply | 1 pharse 220V – 1,1 Kw |
| The hydraulic pump system, electric motor, main electrical cabinet are installed in 01 iron box, with 04 wheels for easy movement. | |
| Control the device by remote or by separate control cabinet | |
*Please contact Tien Ngoc for detailed specifications and the most accurate quote.
